Glory UW-F Series Note Sorter

Glory UW-F Series Note Sorter

The Glory UW-F Series Note Sorter is a high-throughput professional banknote sorter with UV and magnetic counterfeit detection for banks, casinos, and high-volume cash processing facilities across the UAE.

The Glory UW-F Series is a high-capacity banknote processing and sorting system designed for organisations with the largest cash volumes — banks' central cash processing centres, casino cash cages, and large-scale retail cash offices where throughput requirements exceed what a teller-desk sorter can handle. The UW-F processes banknotes at high speed with UV (ultraviolet) and MG (magnetic ink) sensor detection on every note, feeding notes through continuous-feed processing with a large hopper input capacity and multiple output pockets for simultaneously sorted stacks of different denominations or fitness categories. The system can be integrated with downstream cash automation equipment in fully automated cash centre workflows, and a touchscreen operator interface provides job setup, denomination configuration, and count reporting.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Counterfeit Detection
UV, MG, IR, MT, CIS, SD, Image
Weight
20 kg

Key features

01
High-Throughput Banknote Sorting
Processes high volumes of banknotes per hour for central cash processing centre, casino, and large-scale retail cash operations.
02
UV and Magnetic (MG) Counterfeit Detection
Applied to every note during sorting for reliable authentication of banknotes in high-volume cash streams.
03
Multiple Output Pockets
Simultaneously sorts into multiple output stacks by denomination or fitness category for efficient downstream cash handling.
04
Large Hopper Input Capacity
Accepts large input stacks for uninterrupted processing during high-volume runs without frequent reloading.
05
Touchscreen Operator Interface
Job setup, denomination configuration, batch size settings, and count reporting from the touchscreen panel.
06
Integration Capability
Designed to integrate with cash centre automation equipment in fully automated banknote processing workflows.
07
Fitness Sorting
Separates fit recirculable notes from worn, damaged, and soiled unfit notes for banknote quality management.
08
Denomination Recognition
Identifies notes by denomination and value for accurate inventory counting and reporting at end of run.

Specifications

Display
Display5" colour touchscreen
Performance
Counterfeit DetectionUV, MG, IR, MT, CIS, SD, Image
Connectivity
ConnectivityUSB, Ethernet, RS-232, SD card slot
Power
Power Consumption60 W (max)
Power Source100-240 V AC, 50/60 Hz
Physical
Dimensions300 x 400 x 500 mm
Hopper Capacity500 notes (hopper); 200 notes (stacker)
Weight20 kg
Compliance
Country of OriginJapan
