Fluke 1745 Basic Power Quality Logger
- SKU: Fluke 1745Basic
Actual Stock & Price Can Be Confirmed After Placing the Order.
The Fluke 1745 Basic Three-Phase Power Quality Logger is a DIN-rail-mounted three-phase power quality recording instrument for EN 50160 compliance monitoring and long-term PQ assessment in commercial and industrial electrical installations across the UAE.The Fluke 1745 Basic is a Memobox-format three-phase power quality logger... See More
The Fluke 1745 Basic Three-Phase Power Quality Logger is a DIN-rail-mounted three-phase power quality recording instrument for EN 50160 compliance monitoring and long-term PQ assessment in commercial and industrial electrical installations across the UAE.
The Fluke 1745 Basic is a Memobox-format three-phase power quality logger positioned above the 1743-BASIC in the Fluke PQ Memobox range, offering extended parameter recording and a larger memory capacity for longer continuous monitoring campaigns. The 1745 records voltage, current, power, reactive power, power factor, and frequency across all three phases plus neutral simultaneously, and captures power quality events including voltage dips and swells, transients, rapid voltage changes, and harmonics to 50th order. Its CT interface allows installation in existing switchboards without disconnecting live conductors, and the instrument can run unattended for extended periods. Data is downloaded to Fluke Power Log software for automated EN 50160 compliance assessment and detailed event analysis reporting.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Key Features
- DIN-Rail Memobox Format – Compact panel-mount format for semi-permanent switchboard installation and long-term unattended monitoring.
- Extended Parameter Recording – Records voltage, current, active/reactive/apparent power, power factor, and frequency on all phases simultaneously.
- Harmonics to 50th Order – Full harmonic spectrum recording per phase for THD and individual harmonic reporting to EN 61000-3-2.
- EN 50160 Power Quality Compliance Assessment – Data analysis in Power Log software generates automated EN 50160 pass/fail compliance reports.
- Voltage Event Logging – Captures and classifies dips, swells, transients, and interruptions with event waveform capture.
- CT Interface – Connects to existing switchboard CTs for installation without disconnecting live power circuits.
- Large Internal Memory – Extended memory for multi-month continuous monitoring campaigns without data download.
- Fluke Power Log Software – PC software for automated compliance reporting, event analysis, and trend visualization.
Ideal for: power quality engineers, energy consultants, facilities managers, and MEP contractors conducting EN 50160 compliance monitoring and long-term PQ assessment in commercial buildings, industrial plants, data centres, and hotels across Dubai, Abu Dhabi, Sharjah and the wider GCC.
| Name | Fluke 1745 Basic Power Quality Logger |
| Country of Origin | USA |
| Dimensions | 23 x 14 x 6 mm |
| Warranty | 1 year |
| Weight | 0.5 kg |
| Display | Backlit color display with waveform display capability |
| Frequency Range | 40 Hz - 70 Hz |
| Operating Temperature | 0°C to 50°C |
| Voltage Range | 600 V |
No datasheet available.
Frequently Asked Questions
Where can I buy the Fluke 1745 PQ Logger in the UAE?
Procure.ae is an authorized UAE supplier of Fluke test and measurement instruments, with delivery across Dubai, Abu Dhabi, Sharjah and the GCC, and procurement-ready quotations for power quality and facilities engineering buyers.
What is the difference between the Fluke 1743-BASIC and the Fluke 1745?
Both instruments are DIN-rail Memobox format three-phase PQ loggers. The 1745 typically offers extended parameter recording, more measurement channels, or larger memory capacity compared to the 1743-BASIC — making it suited to more demanding continuous monitoring applications where fuller parameter coverage and longer between-download intervals are needed. Contact Procure.ae for a detailed specification comparison between the two models.
Does it include a warranty?
Procure.ae provides manufacturer-backed warranty support for all Fluke products. Contact us for the full warranty details applicable to this model.
Is this available with delivery and support across the UAE?
Yes — Procure.ae supplies it across Dubai, Abu Dhabi, Sharjah and the wider GCC, with procurement-ready quotations and after-sales support.
Can I get a demo or bulk/tender pricing?
Yes — we offer demos and volume pricing for corporate, education, and government buyers. Contact us for a tailored quote.
